Chicago SolidWorks Users Group For SolidWorks Users .. By Chicago Area SolidWorks Users

Chicago Solidworks Users Group

Welcome to the Chicago SolidWorks Users' Group Website! The Chicago SolidWorks Users' Group provides a forum for learning and information exchange among Chicago area SolidWorks users.

The Chicago SolidWorks Users' Group, (CSUG), is a Not-For-Profit organization for Chicago area professionals involved in the use of SolidWorks.

Our group is composed mostly of engineering and industrial design professionals, but anyone interested in SolidWorks is welcome and encouraged to join.

Next CSUG Meeting January 22, 2019.

president January 8th, 2019

Chicago SOLIDWORKS User Group

Dear CSUG member,

We are planning a CSUG meeting for Tuesday, January 22, 2019 from 5pm to 8:30pm at the DES PLAINES Campus of Oakton Community College, in ROOM 1608. The address is 1600 E. Golf Rd., Des Plaines, Illinois 60016. (See map at end of notice or Google the address for a map.)

We will start with a short business meeting followed by the presentation.

AGENDA:

5:00-5:30PM Sign-in and networking.
5:30PM Food served. Pizza & soft drinks.
5:30-6:00PM Short business meeting during pizza time.
6:00-6:30PM Partner Spotlight – MiSUMi USA
6:30-8:00PM Presentation – Modelling Curvy Stuff…
8:00-8:30PM Q&A, Door Prize Drawing.
8:30PM Meeting adjourned.

Partner Spotlight:
MiSUMi USA and their Rapid Design tool for SOLIDWORKS (www.misumirapiddesign.com)
Carlicia Layosa | Marketing Product Engineer | MISUMI USA

Carlicia Layosa is a Marketing Product Engineer at MISUMI USA. She holds a degree in Mechanical Engineering from the University of Illinois at Chicago and is pursuing her Master’s in Energy Engineering. She is a Certified SOLIDWORKS Associate and a Marketo Certified Expert with a passion for education and training.

Presentation:
Modelling Curvy Stuff – Controlling the “Flow” of Isoparms and Why that Matters a Lot
Ed Eaton | Sr. Industrial Designer | DiMonte Group Inc.

Ed has presented at SOLIDWORKS World several times.
This is Ed’s SWW2019 presentation.

Ever get wrinkles or bulges/dips in your surfaces, or strange edge anomalies when trying to make a Loft/Boundary? You need the tips and tricks in this session for controlling the “flow” of isoparms, the matrix created between the edges and curves of a Loft/Boundary that define the faces of your product.

Attendees will learn: What isoparms are; How to see them (unlike curves and edges, they are by default hidden from the user); Why they matter; What you really want them to look like to make great surfaces and learn how to control them.

We will have the usual pizza and soft drinks for refreshments, along with a door prize drawing (if we have prizes to give away).

The meeting should adjourn around 8:30pm.

No RSVP necessary.
We will base the headcount on the average from previous meetings.

Looking forward to seeing the familiar faces along with any new members.

Solidly Yours,
Denny Bahl
CSUG President

Next CSUG Meeting November 13, 2018.

president November 7th, 2018

Chicago SOLIDWORKS User Group

Dear CSUG member,

We are planning a CSUG meeting for Tuesday, November 13, 2018 from 6:00pm to 8:30pm at the DES PLAINES Campus of Oakton Community College, in ROOM 1606. The address is 1600 E. Golf Rd., Des Plaines, Illinois 60016. (See map at end of notice or Google the address for a map.)

We will start with a short business meeting followed by the presentation.

AGENDA:

6:00-6:30PM Sign-in and networking.
6:30PM Food served. Pizza & soft drinks.
6:30-7:00PM Short business meeting during pizza time.
7:00-8:00PM Presentation – SLUGME 2018
8:00-8:30PM Q&A, Door Prize Drawing.
8:30PM Meeting adjourned.

Presentation:
SOLIDWORKS Tips and Tricks you need to know – SLUGME Edition
Neil Custard | 3Di Design

Picking up from fellow users Neil has come up with a presentation on using tools to a deeper use. Neil will go deeper into some tools and go over some other tools that he doesn’t see used enough and should be used more.

Neil Custard has used SOLIDWORKS since its beginnings in 1996 and is one of the fastest 3D modelers on the planet having earned first place in the SOLIDWORKS World 2012 Model Mania contest in San Diego, CA as well as placing second in 2008 and third in 2010. Neil owns and runs CADXpad.com (formerly SolidWorksTips.com since 1999) that has helped millions of users over its time online. Neil’s background includes years of training users, tech support, consulting and full-time engineering on some of the smallest parts to the largest in the world.

This will be the Third Annual SOLIDWORKS Largest User Group Meeting Ever (SLUGME) meeting. Groups from across the world will all patch in for a simulcast.

We will have the usual pizza and soft drinks for refreshments, along with a door prize drawing (if we have prizes to give away).

The meeting should adjourn around 8:30pm.

No RSVP necessary.
We will base the headcount on the average from previous meetings.

Looking forward to seeing the familiar faces along with any new members.

Solidly Yours,
Denny Bahl
CSUG President

CSUG 20th Anniversary Celebration Night at the Ballpark

president July 18th, 2018

CSUG 20th Anniversary Celebration Night at the Ballpark

Dear CSUG & CWSUG members,

We are planning a combined CSUG & CWSUG celebration meeting for Thursday, August 23, 2018 from 5pm to end of game at Northwestern Medicine Field 34W002 Cherry Lane, Geneva, IL 60134. Home of the Kane County Cougars. (See map at end of notice or Google the address for a map. Go to www.kccougars.com for additional information.)

PLEASE R.S.V.P. to csug.info@gmail.com by August 7, 2018. R.S.V.P. is mandatory to ensure yourself a ticket.

2018 marks the 20th year for the Chicago SOLIDWORKS User Group. The first meeting of the Chicago SOLIDWORKS User Group was held on May 6, 1998 at the offices of Computer Aided Technology in Northbrook, IL. Thirteen attendees from eight different companies were present.

AGENDA:

5:00-5:30PM Sign-in and networking.
5:30-6:30PM Special Guest introductions, presentations, etc.
6:30-8:30PM Food served, 2hr. All-You-Can-Eat Ballpark Buffet
6:30PM 1st Pitch, enjoy the game and comradery of fellow SOLIDWORKS enthusiasts.
End of Game Meeting adjourned

This will be a special combined meeting of the Chicago SOLIDWORKS User Group and the Chicago West SOLIDWORKS User Group. The purpose of this meeting will be to celebrate 20yrs. of local SOLIDWORKS fellowship. No formal technical presentation will take place this evening; instead we will all enjoy an evening at the ballpark with the friends we have made over the last 20 years.

DETAILS:
This meeting will be held in the “Super Suite” located directly behind and above home plate. We will enjoy a panoramic view of the on-field action from the Super Suite, a climate-controlled interior area, as well as private outdoor stadium seating.

After parking head to the far left corner as you face the stadium, area by the flag poles, look for the Cougars Front Office, see attached map of the stadium. Enter the Cougars Front Office through the glass doors. There will be a Cougars representative inside to greet you. After verifying that you are on the guest list you will receive your ticket/wristband and be directed up to the Super Suite. Your ticket/wristband will allow you to walk around other areas of the ballpark and allow you back upstairs to the Super Suite.

Ticket/Wristband Cost:
$0.00 if you R.S.V.P. by the deadline stated above.
This is courtesy of our generous sponsors.
(If you happen to show up without sending a RSVP the cost will be $39.00. This does not guarantee entry and you may be turned away at the door.)

Parking:
General parking is available on the night of the event at a cost of $10.00 CASH ONLY, per vehicle.
Preferred parking is available for $15.00 per vehicle and must be pre-purchased. Please go to www.kccougars.com to pre-purchase Preferred Parking Passes or call 630-232-8811 to order.

Directions:
Please go to www.kccougars.com.

Thank you to our generous sponsors:

Dassault Systemes SolidWorks Corporation
www.solidworks.com

Sterling Engineering, Inc.
www.sterling-engineereing.com

Computer Aided Technology, Inc.
www.cati.com

GSC
www.gsc-3d.com

Fisher Unitech
www.fisherunitech.com

DESIGN ENGINE
www.design-engine.com

DriveWorks Ltd.
www.driveworks.co.uk

RAPID (A Protolabs Company)
www.rapidmanufacturing.com

R & S Design
www.randsdesign.com

REMINDER!!!
PLEASE R.S.V.P. to csug.info@gmail.com by August 7, 2018. R.S.V.P. is mandatory to ensure yourself a ticket.

Looking forward to seeing the familiar faces along with any new members.

Solidly Yours,
Denny Bahl
CSUG President

Next CSUG Meeting April 24, 2018.

president April 12th, 2018

Chicago SOLIDWORKS User Group

Dear CSUG member,

We are planning a CSUG meeting for Tuesday, April 24, 2018 from 5:30pm to 8:30pm at the DES PLAINES Campus of Oakton Community College, in ROOM 1610. The address is 1600 E. Golf Rd., Des Plaines, Illinois 60016. (See map at end of notice or Google the address for a map.)

We will start with a short business meeting followed by the presentation.

AGENDA:
5:30-6:00PM Sign-in and networking.
6:00PM Food served. Pizza & soft drinks.
6:00-6:30PM Short business meeting during pizza time.
6:30-8:00PM Presentation – “SOLIDWORKS Sheet Metal – You think you know sheet metal.”
8:00-8:30PM Q&A, Door Prize Drawing.
8:30PM Meeting adjourned.

Presentation:
“SOLIDWORKS Sheet Metal – You think you know sheet metal.”
Bart Brejcha
Lead Instructor
Design Engine – Chicago

This presentation will start out as an advanced presentation converting a solid part (enclosure) into a sheet metal part, and then utilize conversion in order to create a manageable sheet metal part. We will also cover the basics of sheet metal in SOLIDWORKS 2018.

We will have the usual pizza and soft drinks for refreshments, along with a door prize drawing (if we have prizes to give away).

The meeting should adjourn around 8:30pm.

No RSVP necessary.
We will base the headcount on the average from previous meetings.

Looking forward to seeing the familiar faces along with any new members.

Solidly Yours,
Denny Bahl
CSUG President

Next CSUG Meeting January 30, 2018.

president January 15th, 2018

Chicago SOLIDWORKS User Group

Dear CSUG member,

We are planning a CSUG meeting for Tuesday, January 30, 2018 from 5pm to 8:30pm at the DES PLAINES Campus of Oakton Community College, in ROOM 1608. The address is 1600 E. Golf Rd., Des Plaines, Illinois 60016. (See map at end of notice or Google the address for a map.)

We will start with a short business meeting followed by the presentation.

AGENDA:
5:00-5:30PM Sign-in and networking.
5:30PM Food served. Pizza & soft drinks.
5:30-6:00PM Short business meeting during pizza time.
6:00-8:00PM Presentation – Achieving Extreme SOLIDWORKS Performance: Modeling
8:00-8:30PM Q&A, Door Prize Drawing.
8:30PM Meeting adjourned.

Presentation:
Achieving Extreme SOLIDWORKS Performance: Modeling
Bryan Pawlak, CSWE
Sr. Application Engineer
Computer Aided Technology (CATI)

Bryan has presented at SOLIDWORKS World several times.
This is Bryan’s SWW2018 presentation.

This session will present a case study in which part and assembly modeling techniques went wrong. Using standard SOLIDWORKS tools, attendees will discover the issues and how to correct them. With a set of production files, this session will show the mistakes and how to resolve them to increase performance.

Attendees will learn the process for troubleshooting and resolving slow part and assembly performance using the SOLIDWORKS® functions available to every SOLIDWORKS user.

We will have the usual pizza and soft drinks for refreshments, along with a door prize drawing (if we have prizes to give away).

The meeting should adjourn around 8:30pm.

No RSVP necessary.
We will base the headcount on the average from previous meetings.

Looking forward to seeing the familiar faces along with any new members.

Solidly Yours,
Denny Bahl
CSUG President

Next CSUG Meeting November 15, 2017.

president November 1st, 2017

Chicago SOLIDWORKS User Group

Dear CSUG member,

We are planning a CSUG meeting for Wednesday, November 15, 2017 from 5:30pm to 8:00pm at the DES PLAINES Campus of Oakton Community College, in ROOM 1610. The address is 1600 E. Golf Rd., Des Plaines, Illinois 60016. (See map at end of notice or Google the address for a map.)

We will start with a short business meeting followed by the presentation.

AGENDA:

5:30-6:00PM Sign-in and networking.
6:00PM Food served. Pizza & soft drinks.
6:00-6:30PM Short business meeting during pizza time.
6:30-7:30PM Presentation – SLUGME 2017 All The Small Things
7:30-8:00PM Q&A, Door Prize Drawing.
8:00PM Meeting adjourned.

Presentation:
SLUGME 2017 – All The Small Things
Todd Blacksher | Design Engineer | TMCO Inc.
SOLIDWORKS User Group of Nebraska (SWUGONE)

“All The Small Things”, a wide variety of Tips & Tricks, which should have something for everyone. The majority of the presentation will be spent working in SOLIDWORKS, and showing tips and tricks that people may or may not know about. Keyboard Shortcuts, User Interface, Sheet Metal, Weldments, Templates, and Custom Properties are just a few of the things on the menu.

Todd Blacksher started using SOLIDWORKS in 2002, earned his CSWP in 2005, CSWE in 2015 as well as 11 other certifications in between. He has worked in the fields of electronics, aviation, automation equipment, and laboratory test equipment manufacturing in addition to working as an Application Engineer for his local SOLIDWORKS VAR. He got married to his wife, Jade, at SOLIDWORKS World 2006. They have two spoiled dogs and an impressive collection of bicycles that they ride as much as possible.

This will be the Second Annual SOLIDWORKS Largest User Group Meeting Ever (SLUGME) meeting. Groups from across the world will all patch in for a simulcast.

We will have the usual pizza and soft drinks for refreshments, along with a door prize drawing (if we have prizes to give away).

The meeting should adjourn around 8:00pm.

No RSVP necessary.
We will base the headcount on the average from previous meetings.

Looking forward to seeing the familiar faces along with any new members.

Solidly Yours,
Denny Bahl
CSUG President

Next CSUG Meeting May 2, 2017.

president April 27th, 2017

Chicago SOLIDWORKS User Group

Dear CSUG member,

We are planning a CSUG meeting for Tuesday, May 2, 2017 from 5pm to 8:30pm at the DES PLAINES Campus of Oakton Community College, in ROOM 2816. The address is 1600 E. Golf Rd., Des Plaines, Illinois 60016. (See map at end of notice or Google the address for a map.)

We will start with a short business meeting followed by the presentation.

NOTE: THE ROOM LOCATION IS #2816.

AGENDA:

5:00-5:30PM Sign-in and networking.
5:30PM Food served. Pizza & soft drinks.
5:30-6:00PM Short business meeting during pizza time.
6:00-8:00PM Presentation – The Bronze Doors Project
8:00-8:30PM Q&A, Door Prize Drawing.
8:30PM Meeting adjourned.

Presentation:
The Bronze Doors Project @ The Museum of Science and Industry, Chicago, IL.
Matthew Cummins | Artist in Residence | Museum of Science and Industry, Chicago, IL

Matthew gave this presentation this year at SOLIDWORKS World.

This presentation shows how MSI’s first-ever Artist in Residence, a longtime SOLIDWORKS user, is leveraging original circa 1930s blueprints, 3D scans, additive manufacturing and materials science to resurrect the museum’s historic Bronze Doors for an 85th anniversary celebration.

This presentation aspires to blend technical and inspirational benefits. Attendees will see case studies of several technologies including 3D scanning, industrial-scale additive manufacturing and materials technology. This presentation also showcases STE(A)M innovation within a large educational institution.

We will have the usual pizza and soft drinks for refreshments, along with a door prize drawing (if we have prizes to give away).

The meeting should adjourn around 8:30pm.

No RSVP necessary.
We will base the headcount on the average from previous meetings.

Looking forward to seeing the familiar faces along with any new members.

Solidly Yours,
Denny Bahl
CSUG President

Next CSUG Meeting January 24, 2017.

president January 5th, 2017

Chicago SOLIDWORKS User Group

Dear CSUG member,

We are planning a CSUG meeting for Tuesday, January 24, 2017 from 5pm to 8:30pm at the Des Plaines Campus of Oakton Community College, in ROOM 1610 The address is 1600 E. Golf Rd., Des Plaines, Illinois 60016. (See map at end of notice or Google the address for a map.)

We will start with a short business meeting followed by the presentation.

AGENDA:

5:00-5:30PM Sign-in and networking.
5:30PM Food served. Pizza & soft drinks.
5:30-6:00PM Short business meeting during pizza time.
6:00-8:00PM Presentation – Using 3D scan data effectively…
8:00-8:30PM Q&A, Door Prize Drawing.
8:30PM Meeting adjourned.

Presentation:
Using 3D scan data effectively, and how to model curvy stuff from it.
By Ed Eaton | Sr. Industrial Designer | DiMonte Group Inc.

Ed has presented at SOLIDWORKS World several times.
This is Ed’s SWW2017 presentation.

So you have 3D scan data. Now what???
This session first explores the workflows and decisions required to effectively reference a 3D scan in SOLIDWORKS.
Then the second part uses the “Tucker Torpedo” case study to explore the root principles and best tools for modeling using the scan as your guide.

We will have the usual pizza and soft drinks for refreshments, along with a door prize drawing (if we have prizes to give away).

The meeting should adjourn around 8:30pm.

No RSVP necessary.
We will base the headcount on the average from previous meetings.

Looking forward to seeing the familiar faces along with any new members.

Solidly Yours,
Denny Bahl
CSUG President

Next CSUG Meeting Dec. 07, 2016.

president November 23rd, 2016

Chicago SolidWorks User Group will participate in SLUGME.
Come on out and be part of SolidWorks Largest User Group Meeting Ever.

Dear CSUG member,

We are planning a CSUG meeting for Wednesday, December 7, 2016 from 6pm to 8:30pm at the Skokie Campus of Oakton Community College, in ROOM P103 The address is 7701 N. Lincoln Avenue,

Skokie, Illinois 60077. (See map at end of notice or Google the address for a map.)

We will start with a short business meeting followed by the presentation.

AGENDA:

6:00-6:30PM Sign-in and networking.
6:15-6:30PM Food served. Pizza & soft drinks.
6:30-7:00PM Short business meeting during pizza time.
7:00-8:00PM Presentation – Best Practices for Large Assemblies
8:00-8:30PM Q&A, Door Prize Drawing.
8:30PM Meeting adjourned.

Presentation:
Best Practices for Large Assemblies
By Tom Cote, Applied CAD Solutions

Tom has presented at SOLIDWORKS World several times. Tom currently leads (2) user groups the BANSWUG & CMASWUG, and is an all-around great guy on top of that!
This is being billed as “SOLIDWORKS Largest User Group Meeting Ever”, (SLUGME), and for such a large gathering it is apropos to have the topic be on Large Assemblies.
This presentation is being broadcast over the Internet to facilitate this large gathering of User Groups on one night.
We will log into a Webinar with other User Groups from all over to take part in this first ever SLUGME event.

We will have the usual pizza and soft drinks for refreshments, along with a door prize drawing (if we have prizes to give away).

The meeting should adjourn around 8:30pm.

No RSVP necessary.
We will base the headcount on the average from previous meetings.

Looking forward to seeing the familiar faces along with any new members.

Solidly Yours,
Denny Bahl
CSUG President

Next CSUG Meeting October 25, 2016.

president October 17th, 2016

Chicago SolidWorks User Group

Dear CSUG member,

We are planning a CSUG meeting for Tuesday, October 25, 2016 from 5pm to 8:30pm at the DES PLAINES Campus of Oakton Community College, in ROOM 1608 The address is 1600 E. Golf Rd., Des Plaines, Illinois 60016. (See map at end of notice or Google the address for a map.)

We will start with a short business meeting followed by the presentation.

AGENDA:

5:00-5:30PM Sign-in and networking.
5:30PM Food served. Pizza & soft drinks.
5:30-6:00PM Short business meeting during pizza time.
6:00-8:00PM Presentation – Activate to Automate – DriveWorksXpress
8:00-8:30PM Q&A, Door Prize Drawing.
8:30PM Meeting adjourned.

Presentation:
Activate to Automate – DriveWorksXpress
By Heather Hasz from DriveWorks

This presentation will cover everything you need to start using DriveWorksXpress. This presentation will lead you through the user interface and workflow. DriveWorksXpress provides entry-level Design Automation inside world-leading, 3D CAD design software, SOLIDWORKS. With this presentation you will see that DriveWorksXpress is ideal for everyday repetitive design tasks.

Heather Hasz is a member of the DriveWorks Business Development team and plays a key part in the DriveWorks SWUGN Sponsorship Program. She works closely with user group leaders to organize DriveWorksXpress presentations across the SOLIDWORKS User Group Network. Heather helps user group leaders to arrange presenters and giveaway prizes. This summer she has been on the road visiting user groups across the country, presenting about DriveWorksXpress – a free tool that sits inside every seat of SOLIDWORKS.

We will have the usual pizza and soft drinks for refreshments, along with a door prize drawing (if we have prizes to give away).

The meeting should adjourn around 8:30pm.

No RSVP necessary.
We will base the headcount on the average from previous meetings.

Looking forward to seeing the familiar faces along with any new members.

Solidly Yours,
Denny Bahl
CSUG President

Next »
